IMP FOR SEPM

Software Engineering & Project Management

Complete Important Questions with Detailed Answers

G H Raisoni College of Engineering & Management

Department of Artificial Intelligence

All Questions Covered | Unit 1 to Unit 4

UNIT 1 — Software Process Models & Requirements Engineering

Q1. Construct the diagram of the V-model and analyse its phases. Also explain the

Incremental Process Model.

The V-Model (Verification and Validation Model):

The V-Model is an extension of the Waterfall Model where each development phase has a directly

corresponding testing phase. The left side of the V represents development (verification) phases and

the right side represents testing (validation) phases. The bottom of the V is coding — the point where

both sides meet.

V-Model Diagram (Text Representation):

Requirements Analysis ←■■■■■■■■■■■■■■■■→ Acceptance Testing

System Design ←■■■■■■■■■■■■■■→ System Testing

Architecture Design ←■■■■■■■■■■■■→ Integration Testing

Module Design ←■■■■■■■■■■→ Unit Testing

CODING

Phases of V-Model:

1. Requirements Analysis ↔ Acceptance Testing: Customer requirements are gathered.

Acceptance tests verify the final product meets user needs.

2. System Design ↔ System Testing: Overall system architecture is designed. System tests

validate the complete integrated system.

3. Architectural Design ↔ Integration Testing: Modules and interfaces are defined. Integration

tests verify that modules work correctly together.

4. Module Design ↔ Unit Testing: Detailed design of individual modules. Unit tests verify each

module works correctly in isolation.

5. Coding: Actual implementation of the software at the bottom of the V.

Advantages of V-Model: Simple and easy to understand; each phase has clear deliverables; defects

are found early; good for small to medium projects with well-defined requirements.

Incremental Process Model:

The Incremental Model divides software into multiple standalone modules (builds). Each module goes

through Requirements → Design → Implementation → Testing independently. Every subsequent

release adds functionality to the previous release until the complete system is achieved.

Phases: 1. Requirement Analysis — identifies functional requirements for the module. 2. Design &

Development — designs and develops the module. 3. Testing — verifies performance of existing

and new functionality. 4. Implementation — final coding and integration.

Advantages: Errors are easy to recognize; easier to test and debug; more flexible; client gets

important functionality early; risk is managed during iterations.

Disadvantages: Needs good planning; total cost is high; well-defined module interfaces needed.

Q2. Describe Functional and Non-Functional Requirements. Differentiate with suitable

examples.

Functional Requirements:

Functional requirements describe WHAT the software system must do. They define the specific

functions, features, and capabilities the system must provide. They are directly visible in the final

product and represent what users expect the system to perform. According to IEEE standard 729, a

requirement is a condition or capability needed by a user to solve a problem or achieve an objective.

Examples: User Authentication (login with username & password); Search functionality (search

products by name/category); Report generation (generate sales reports for a date range); System

sends email notifications when order is placed; CRUD operations on account information; Shopping

cart management (add/remove items).

Non-Functional Requirements:

Non-functional requirements describe HOW the software performs its functions. They define quality

attributes, performance criteria, and constraints. They are also called non-behavioral requirements

and deal with quality standards the system must satisfy.

Types: Interface constraints; Performance constraints (response time, storage); Operating

constraints; Life cycle constraints (maintainability, portability); Economic constraints.

Examples: Performance — system processes 1,000 transactions/second; Usability — user-friendly

interface; Reliability — 99.9% uptime; Security — data encrypted during transmission; Portability —

runs on multiple platforms; Scalability — handles increased load.

Key Differences:

Aspect Functional Requirements Non-Functional Requirements

Definition What the system does How well the system does it

Visibility Directly visible in final product Quality attributes (not directly visible)

Focus System features/functions System performance/quality

Example User login with password Login response in under 2 seconds

Also called Functional Specification Non-behavioral requirements

Q3. Explain the Software Design Process. Describe the role of Architectural Design.

Software Design Process:

The software design process transforms requirements into a blueprint for constructing the software. It

bridges the gap between requirements and implementation by defining system structure, components,

interfaces, and data.

Steps in Software Design Process:

1. Architectural Design: Defines the overall structure and major components of the system.

2. Interface Design: Describes how software elements, hardware, and people interact.

3. Component-Level Design: Detailed design of individual software components/modules.

4. Data/Class Design: Transforms analysis class models into design class realizations and data

structures.

Role of Architectural Design:

Architectural design is the FIRST and most important level of the design process. It identifies the main

structural components of a system and the relationships between them.

Key Roles: Provides the blueprint for the entire system; enables communication among stakeholders;

defines constraints on implementation; promotes reuse of components; dictates development

priorities; helps achieve quality attributes like performance, reliability, and security; establishes how

components interact and communicate.

Architectural Styles:

1. Data-Centered Architecture: A central data store (database) is accessed by client components.

Example: Client-server systems. Advantage: Data is easily shared; components are independent.
