Cyclomatic Complexity may be defined as-
It is a software metric that measures the logical complexity of the
program code.
It counts the number of decisions in the given program code.
It measures the number of linearly independent paths through the
program code.
Cyclomatic complexity indicates several information about the
program code-
Cyclomatic Complexity
Meaning
1 – 10
Structured and Well Written
Code
High Testability
Less Cost and Effort
10 – 20
Complex Code
Medium Testability
Medium Cost and Effort
20 – 40
Very Complex Code
Low Testability
High Cost and Effort
> 40
Highly Complex Code
Not at all Testable
Very High Cost and Effort
Importance of Cyclomatic Complexity-
It helps in determining the software quality.
It is an important indicator of program code’s readability, maintainability and portability.
It helps the developers and testers to determine independent path executions.
It helps to focus more on the uncovered paths.
It evaluates the risk associated with the application or program.
It provides assurance to the developers that all the paths have been tested at least once.
Properties of Cyclomatic Complexity-
It is the maximum number of independent paths through the program code.
It depends only on the number of decisions in the program code.
Insertion or deletion of functional statements from the code does not affect its
cyclomatic complexity.
It is always greater than or equal to 1.
Calculating Cyclomatic Complexity-
Cyclomatic complexity is calculated using the control flow representation of the program
code.
In control flow representation of the program code,
Nodes represent parts of the code having no branches.
Edges represent possible control flow transfers during program execution
There are 3 commonly used methods for calculating the cyclomatic complexity-
Method-01:
Cyclomatic Complexity = Total number of closed regions in the control flow graph + 1
Method-02:
Cyclomatic Complexity = E – N + 2
Here-
E = Total number of edges in the control flow graph
N = Total number of nodes in the control flow graph
Method-03:
Cyclomatic Complexity = P + 1
Here,
P = Total number of predicate nodes contained in the control flow graph
Note-
Predicate nodes are the conditional nodes.
They give rise to two branches in the control flow graph.
