AP Workbook 2H
Forces on Inclined Planes
Overview
AP Workbook 2H is part of the AP Physics 1 curriculum, specifically within Unit 2: Dynamics. This workbook
section focuses on analyzing forces acting on objects positioned on inclined planes, a fundamental concept in
classical mechanics. Students learn to decompose gravitational force into components parallel and
perpendicular to the inclined surface, understand the relationship between normal force and angle of incline,
and apply Newton's laws to solve complex dynamics problems.
Key Concepts
1. Force Components on Inclined Planes
When an object rests on an inclined plane at angle θ, the gravitational force (weight) must be resolved into two
components: one parallel to the incline (mg sin θ) and one perpendicular to the incline (mg cos θ). The parallel
component causes the object to slide down the plane, while the perpendicular component determines the
normal force.
2. Normal Force and Angle Relationship
The normal force (N) acting on an object at rest on an incline equals mg cos θ, where m is the mass, g is
gravitational acceleration (9.8 m/s
2
), and θ is the angle of incline. This relationship is critical for understanding
how the support force changes as the incline angle varies. As θ increases, the normal force decreases,
reaching zero at θ = 90°.
3. Free-Body Diagrams
Creating accurate free-body diagrams is essential for solving inclined plane problems. The diagram should
show all forces acting on the object: weight (mg) acting vertically downward, normal force (N) perpendicular to
the surface, and friction force (if present) parallel to the surface opposing motion. Proper coordinate system
selection simplifies calculations significantly.
Typical Workbook Scenario
In a common AP Workbook 2H scenario, students are asked to determine the relationship between the normal
force on a box of mass m and the angle of incline θ as the box sits at rest on an inclined plane. This requires
students to:
• Draw a free-body diagram showing all forces acting on the object
• Derive an equation relating normal force to angle and mass
• Analyze experimental data plotting normal force versus angle
• Create linearized graphs to verify the theoretical relationship
• Determine the physical meaning of slopes and intercepts
Essential Equations
Equation Description
F<sub>parallel</sub> = mg sin θ Force component parallel to incline
F<sub>perpendicular</sub> = mg cos θ Force component perpendicular to incline
N = mg cos θ Normal force (object at rest)
f<sub>s</sub> ≤ µ<sub>s</sub>N Static friction (prevents sliding)
f<sub>k</sub> = µ<sub>k</sub>N Kinetic friction (object sliding)
Problem-Solving Strategy
Successfully solving inclined plane problems requires a systematic approach. Follow these steps to ensure
accurate analysis and solution:
Step 1: Draw the Free-Body Diagram
Identify all forces acting on the object. Draw weight (mg) vertically downward, normal force (N) perpendicular to
the surface, and any friction or applied forces.
Step 2: Choose Coordinate System
Align one axis parallel to the incline and one perpendicular. This choice minimizes the number of force
components to calculate.
Step 3: Resolve Forces into Components
Break the weight into components: mg sin θ (parallel) and mg cos θ (perpendicular). Remember: the angle in
the force triangle equals the incline angle.
Step 4: Apply Newton's Second Law
Write ΣF
x
= ma
x
and ΣF
y
= ma
y
for each direction. For objects at rest or moving at constant velocity,
acceleration = 0.
Step 5: Solve the System of Equations
Use algebraic techniques to find unknown quantities. Check that your answer makes physical sense.
Experimental Data Analysis
Workbook 2H typically includes experimental data showing how normal force varies with incline angle. Students
must create linearized graphs to verify theoretical predictions.
Sample Data: Normal Force vs. Angle
Angle (degrees) Normal Force (N)
10 97
15 95
30 85
35 80
