Rules for Quadrilaterals
1. These rules are the same for all quadrilaterals:
a) They are all polygons.
b) The interior angles ALWAYS add to 360 degrees.
2. These are the rules for rectangles
a) The diagonals of a rectangle are congruent and bisect each other.
b) Opposite sides are ALWAYS parallel. A rectangle is also a parallelogram but the reverse is not always true.
c) Are formed when TWO sets of parallel lines meet at right angles (90 degrees).
d) Opposite angles are ALWAYS congruent.
e) Adjacent angles are ALWAYS supplementary (form a straight angle or equal 180 degrees).
3. These are the rules for parallelograms.
a) The diagonals of are NOT congruent BUT they do bisect each other.
b) Opposite sides are ALWAYS parallel.
c) Are formed when TWO sets of parallel lines meet BUT NOT at 90 degrees.
d) Opposite angles are ALWAYS congruent.
e) Adjacent angles are ALWAYS supplementary (form a straight angle or equal 180 degrees).
f) The height is ALWAYS perpendicular to the base.
4. These are the rules for a square.
a) All four sides are always congruent (equal). A square is also a rhombus but the reverse is not always true.
b) The diagonals of are congruent and bisect each other.
c) Diagonals bisect and form four 90 degree angels. Diagonals are also perpendicular.
d) Opposite sides are ALWAYS parallel.
e) Are formed when TWO sets of parallel lines meet at right angles (90 degrees).
f) Opposite angles are ALWAYS congruent.
g) Adjacent angles are ALWAYS supplementary (form a straight angle or equal 180 degrees).
5. These are rules for rhombus (a rhombus is a parallelogram with 4 equal sides):
a) All four sides are always congruent (equal).
b) The diagonals are NOT congruent BUT they do bisect each other.
c) Diagonals bisect and form four 90 degree angles. Diagonals are also perpendicular.
d) Opposite sides are ALWAYS parallel.
e) Are formed when TWO sets of parallel lines meet) BUT NOT at 90 degrees.
f) Opposite angles are ALWAYS congruent.
g) Adjacent angles are ALWAYS supplementary (form a straight angle or equal 180 degrees).
h) The height is ALWAYS perpendicular to the base.
6. These are the rules for a trapezoid:
a) A trapezoid is a quadrilateral with only one pair of parallel lines.
b) The two parallel lines are called the bases
c) The two non- parallel lines are the legs.
d) The vertical adjacent angles are ALWAYS supplementary (form a straight angle or equal 180 degrees).
e) The diagonals ARE NOT congruent.
7. These are the rules for an isosceles trapezoid.
a) A trapezoid is a quadrilateral with one pair of parallel lines.
b) The two parallel lines are called the bases.
c) The two non parallel lines are the legs AND are congruent (that’s why is called an isosceles trapezoid).
d) Adjacent angles are ALWAYS supplementary (form a straight angle or equal 180 degrees).
e) The diagonals ARE congruent BUT do not bisect each other.
8. These are the rules for a kite.
a) A kite is a quadrilateral with two pairs of adjacent, congruent sides. It looks like the kites you see flying in the sky.
b) The diagonals of a kite intersect at 90 degrees.
9. Know this about angles:
a. All angles are measured on the fact that all circles measure 360 degrees. (all of them, no matter how large or small). Each circle only has
360 degrees.
b. A 90 degree angle forms a shape that looks like an upper case L. This can be facing any direction and can even be upside down or tilted like
on a house.
c. Angles that measure less than 90 degrees are called acute angles.
d. All angles that measure exactly to 90 degrees are called ‘right angles’ – regardless of what direction the angle is facing.
e. All angles that measure more than 90 degrees but less than 180 degrees care called obtuse angles.
f. All angles that measure 180 degrees are called straight angles.
g. Two or more angles that add exactly to 90 degrees are called complementary angles.
h. Two or more angles that add exactly to 180 degrees are called supplementary angles.
i. An angle more than 180 but less than 360 degree is called a reflex angle.
10. Know this about lines.
a. Lines that are a certain distance apart and remain that same distance apart, without ever getting closer together or further apart are called
parallel lines.
b. Lines that cross each other and form a right angle when doing so are called perpendicular lines
c. Lines that cross each other without forming a right angle are called intersecting lines.
d. Perpendicular lines are also intersecting lines.
e. Lines cannot be parallel and intersecting (each other) at the same time).
f. Lines can be parallel and intersecting with other lines - like the lines used to form a tic-tac-toe game.
g. A line with periods connected to the line at both ends is called a line segment.
h. A line with a connected period at one end but not the other is called ray.
i. Two rays that share the same end point (period at one end) form an angle.
Remember these ideas:
1) Diagonals are line segments that connect non-adjacent or opposite angles.
2) Adjacent angles in quadrilaterals are on the same side.
3) Congruent means equal (sides are the same length/interior angels are the same).
4) Supplementary angles are two or more angles that from a straight angle (180 degrees).
5) Complimentary angles are two or more angles that form a right angle (90 degrees).
6) Obtuse angles are more than 90 degrees but less than 180 degrees.
7) Bisect means to cut into two equal or congruent smaller pieces.
8) When two lines meet and form a right angle (exactly 90 degrees) they are perpendicular to each other.
9) The apothem is the distance from the center of a regular polygon to the midpoint of a side (must form a right angle).
.
.
