How 1000Mbps connectivity is helping organizations
meet the need for increased network performance
Gigabit Ethernet
Technology and Solutions
Gigabit Ethernet Technology and Solutions
2
Contents
Executive Summary 2
What Is Gigabit Ethernet? 3
Standards Evolution 3
Benefits of Gigabit 4
What Is Driving the Need for Gigabit Speed? 4
Backbones and Switch Stacks 4
Greater Demands on Servers 4
The Ongoing Desktop Revolution 4
Typical Progression 6
Impact of Gigabit Over Copper 6
Gigabit to the Desktop: Is It Time? 6
Key Gigabit Over Copper Specifications 7
Solutions to the Two Most Common Challanges 7
Deployment Considerations 8
Media Selection 8
Testing Existing Cable 8
Implementation Examples 8
Corporate Campus 9
Departmental Deployment 10
Internet Service Provider 11
Fast-Growing Organization 11
Conclusion 11
For More Information 11
Executive Summary
In a scenario all too familiar to network managers, users begin complaining of
slower response times. Network management tools indicate that a high-transaction
server is hogging bandwidth in a shared domain or that server CPU utilization is not
optimal – classic bottleneck symptoms. What’s the best solution? More and more
often, IT managers are turning to Gigabit Ethernet technology.
When Gigabit Ethernet was standardized for fiber optic cabling in the late 1990s,
IT managers began to see the benefits of Gigabit speeds applied to the network
backbone and in the data center. Today, with Gigabit over copper, 1000Mbps
connectivity is being deployed even more widely – including switch stacks, servers
and desktops – using the cabling that is already in place in most buildings.
This paper provides information about Gigabit Ethernet, including the ways your
network can benefit from standard Gigabit implementations, and offers a variety of
deployment examples using fiber and/or copper cabling.
Gigabit Ethernet Technology and Solutions
What Is
Gigabit Ethernet?
Invented by Dr. Robert Metcalf and
pioneered by Intel, Digital and Xerox,
Ethernet has become the most
commonly used LAN technology
worldwide. More than 85% of all
installed network connections are
Ethernet, according to International
Data Corporation (IDC, 2000). As a
transport protocol, Ethernet operates
at Layers 1 and 2 of the 7-layer OSI
networking model, delivering its data
packets to any device connected to the
network cable.
IT managers have found that Ethernet
is simple, easy to use and readily
upgradeable. An organization can
scale from 10 to 100 or 1000Mbps
Ethernet, either network-wide or a
segment at a time, knowing that the
new equipment will be backwards
compatible with legacy equipment.
This reduces the infrastructure
investment that an organization must
make. Ethernet is also a reliable
technology. Experience shows that
it can be deployed with confidence
for mission-critical applications.
Standards Evolution
A prime reason for the success of
Ethernet is the fact that Ethernet
standards, over 25 years old, have
progressed along with networking
requirements. This progression of
standards provides a clear and
straightforward migration path
for companies as their bandwidth
requirements increase.
Gigabit Ethernet has evolved from the
original 10Mbps Ethernet standard,
10BASE-T, and the 100Mbps Fast
Ethernet standards, 100BASE-TX and
100BASE-FX. A 10-Gigabit Ethernet
standard (10,000Mbps) is being
ratified, supported by the IEEE and
the 10-Gigabit Ethernet Alliance.
In June of 1998, the IEEE adopted a
standard for Gigabit Ethernet over fiber
optic cabling, IEEE 802.3z, and its
implementation was widely supported
by networking vendors. As a result,
companies could rely on a well-
understood, standards-based approach
to improve traffic flow in congested
areas. A year later, in June of 1999,
the IEEE standardized IEEE 802.3ab
Gigabit Ethernet over copper as
1000BASE-T, allowing Gigabit
speeds to be transmitted over Cat-5
cable (Figure 1).
In general, upgrading to Gigabit
Ethernet over copper is ideal even when
budgets are tight, because it increases
performance by building on a company’s
current investment in cabling. Typically,
the network infrastructure simply
adjusts to this higher speed. No
technician re-training is needed, and
any disruption to the network is usually
minimal. What’s more, Gigabit over
copper is the most economical cabling
choice in terms of cost per Mbps.
Gigabit Ethernet is also a good choice
because it supports Quality of Service
(QoS) methods that are increasingly
important for avoiding latency
problems as voice, video and data
share the cable for Next-Generation
Networking (NGN) applications. Like
Fast Ethernet, Gigabit Ethernet
supports existing traffic management
techniques that deliver Quality of
Service over Ethernet, such as IEEE
802.1p traffic prioritization and Multi
Protocol Label Switching (MPLS).
Media Acces Control (MAC)
Full Duplex/Half Duplex
Fiber Channel
Encoder/Decoder
Copper PHY
Encoder/Decoder
Singlemode
Fiber - 5Km
1000BASE-LX 1000BASE-SX 1000BASE-CX 1000BASE-T
GMII - Gigabit Media Independent Interface
(Similar to AUI)
Multimode
Fiber - 550m
Short-haul
Copper - 25m
Long-haul
Copper - 100m
Figure 1
Cahners In-Stat Group, 5/01
3
The Gigabit Ethernet Standards
IEEE 802.3z (June 1998)
IEEE 802.3ab (June 1999)
MAC
PHY
/ 12
