The Basics of Testing a Mass Air
Flow (MAF) Sensor
A MAF sensor can be tested without a scan tool. How? With a digital multimeter. Yes, a
digital multimeter can be used in testing the Mass Air Flow (MAF) Sensor. This
test is almost but not exactly the same for all types of MAF Sensors. So, what's the
difference?
The biggest difference between MAF Sensors is the output type of the MAF Sensor's
Signal to the ECM (Fuel Injection Computer). This signal may be an Analog Voltage
Signal or a Hertz Frequency Signal. Both types can be tested with a multimeter! Ok,
now where do you start?
You can start here, 'cause this site is full of specific MAF Sensor Testing articles to
address the specific vehicle you're working on.
MAF Sensor Tests are available for the following makes: Buick, Chevrolet, Ford,
GMC, Isuzu, Mazda, Mercury, Lexus, Nissan, Oldsmobile, Toyota, Volkswagen,
and Volvo.
Below is a complete example of a MAF Test as it applies to a 1994 Nissan D21 Pick Up.
So if you want to take a look at how simple and easy a MAF Sensor Test can be, read
on!!
If you want to skip this article and go directly to this site's index of MAF Sensor Tests,
click on the link that says 'See full list of Makes...' on the Box titled Mass Air Flow
Sensor Tests on the right of this page. This is the second from the top box.
Example of MAF Sensor Test
The most common symptoms of a BAD MAF Sensor are:
1. A MAF sensor code.
2. Lean and/or Rich code(s).
3. Fuel Trim code(s).
4. A tremendous lack of power upon acceleration.
5. Black smoke coming from the tail-pipe.
6. Vehicle may idle rough and stall.
As stated before, the Mass Air Flow Test is a very easy and simple test but there are
a couple of things that have to be done first.
The most important thing to do first, is to make sure your MAF Sensor isn't
contaminated with dirt and/or oil, since the tests in this article assume the MAF sensor
isn't contaminated. Why? Because this MAF Sensor is a hot-wire type that easily
becomes contaminated with dirt and stuff from the air filter not performing its job.
Cleaning this type of Sensor is easy since the hot-wires are clearly visible to the eye
(with the sensor removed).
This contamination will cause the sensor to produce a lower reading to the ECM
(Engine Control Module = Fuel Injection Computer). The most common symptom of this
contamination is a hesitation or a time-lag in engine responce that is felt after the
accelerator pedal is depressed. As stated in the list at the beginning of this article, other
symptoms may include but are not limited to: higher tailpipe emissions and diagnostic
codes that may illuminate the "Check Engine" light.
If cleaning the MAF Sensor, use an electronics spray cleaner to do it with. This in itself
may solve your problem. Don't use carb or brake clean spray. These solvents can
damage the sensor. Also, don't attempt to physically clean the sensor with anything.
Check your local autopart store, they will have MAF Sensor cleaning spray.
After having checked for contamination the other things that you must check for (and
eliminate if present) are:
1. That the engine does not have any vacuum leaks.
2. That there are no ignition system misfires. A misfire condition will skew
the results of the test you'll perform here.
If the above conditions exist, repairing them first will more than likely solve your
vehicle's drive-ability issue without having to test the MAF Sensor, if not continue with
the MAF Test in this article.
THE MAF TEST
OK, you're gonna' start by checking the Mass Air Flow (MAF) Sensor basics. These
are 12 Volts and Battery ground to the MAF Sensor. After that, we'll test the actual
performance of the MAF Signal as the engine is running. Use a digital multimeter for all
tests where a multimeter is called for.
The MAF sensor produces an analog voltage signal. At idle with the engine at its normal
operating temperature, the MAF sensor produces a signal of 1.0 volts to 1.7 volts. The
MAF Sensor's operating voltage range is from .0 to 5 volts.
The MAF Signal's voltage is directly related to amount of air the engine is breathing.
Common sense tells us that the engine will breathe in more air at 2500 RPMs than at an
idle of 900 RPMs.
So keeping this in mind, the Voltage value on the multimeter will be greater at 2500
RPMs than at 900 RPMs
Now, when testing this voltage signal, the important thing to know is not an actual volts
number at a specific RPM, but to look for crazy and extreme fluctuations in the voltage
signal that do not correspond to the actual air intake (RPM's) of the engine. For
example: If at Idle the voltage reading starts to spike up and down without you
accelerating the engine.
In the TEST 3 section of this article, I'll show how you'll use a base voltage reading at
idle from the MAF Sensor that will help you to confirm that the MAF Sensor is bad or
not.
Lastly, these tests are not designed to diagnose an intermittent problem with the MAF
sensor. They are designed to diagnose a hard fault with the sensor.
TEST INFO: A Description Of The Circuits
To effectively test the MAF Sensor, we
need to know what each wire does in
the MAF sensor connector.
The safest way to test these circuits, and
the method I always use, is using a wire
piercing probe. (click here to see a picture
of this tool). Using this probe, I don't have
to disconnect the MAF Sensor's connector
to probe the front of the female terminal
and possibly risk damaging it.
Independent of the method you use, be
careful not to damage the wire or the
female terminal. Take all safety precautions.
IMPORTANT- All of the tests are ON CAR TESTS, do not remove or disconnect the
mass air flow sensor from the vehicle or from its plumbing.
As you've already noticed, the photo (above) has the MAF Connector lettered A thru' C.
If you take a close look at the MAF Sensor, you'll see these same letters on it too. I'll be
using these letters for the circuit descriptions. Here's the description of each circuit
below.
ï‚· Letter A- 12 Volt battery power.
ï‚· Letter B- MAF Signal.
ï‚· Letter C- Ground. Provided by the ECM internally.
We're ready to get started...
Testing the Power
Circuit of the Mass Air Flow Sensor
The very first thing that we'll do is check that the MAF Sensor is receiving 12
volts. Again, the procedure I recommend to use (to accomplish all of the tests below) is
to use a test probe that pierces thru' the wire's insulation (click here to see a picture of
this tool). DO NOT insert anything into the female terminal.
Whatever method you use, the key here is not to damage the female terminal or the
wire. Again, be careful. Use common sense and take all necessary safety precautions.
